How to Set Smart Mode Sprinkler Type in SmartLink

Learn how to set the sprinkler type for your zones in SmartLink Network by following the instructions below

Step 1: Log In and Select Your Controller

1. Go to smartlinknetwork.com and enter your login credentials to access your account.
2. On the Site Page, find the search bar and type in and select your Site Name from the search results.
3. Then click on the Controller name
   -OR-
4. Locate the Controller List at the top, then find and click the Controller name.

Step 2: Access Smart Mode Settings

1. On the Controller Page, scroll down to the Programming section.
2. Click the Smart Mode Auto Adjust button.

Step 3: Edit Sprinkler Type

1. Under the My Sprinkler Type column, you will see the current sprinkler types for each zone.
2. Click Edit Smart Settings to enter the edit mode.
3. Select the Pencil Icon next to the zone you want to modify, or simply click anywhere in that box.
4. Choose from the following sprinkler types in the drop down menu:
   • Standard (Non-ET) - Allows the zone to run in Basic Mode.
   • Off - No irrigation will occur.
   • Spray - 1.5 inches per hour precipitation rate.
   • Rotor - Adjusted for rotor systems. (MRP Nozzles should be set to custom 0.4" PR)
   • Drip - Low-volume irrigation.
   • Bubbler - Suitable for concentrated watering.
5. Remember, zones with a higher precipitation rate will run for a shorter period, while lower precipitation rates will result in longer run times.

Step 4: Save and Send Changes

1. After making adjustments, click Stop Editing to save your selections.
2. Click the red Send button at the top right corner to apply your changes to the controller.
3. The system will show a Successfully Sent banner once the communication is complete.
