How to Adjust the Seasonal Percentage from SmartLink

Learn how to adjust the Seasonal Percentage in SmartLink Network by following the instructions below

Step 1: Log In and Select Your Controller

1. Go to smartlinknetwork.com and enter your login credentials to access your account.
2. On the Site Page, find the search bar and type in and select your Site Name from the search results.
3. Then click on the Controller name
   -OR-
4. Locate the Controller List at the top, then find and click the Controller name.

Step 2: Access Seasonal Adjust Settings

• On the Controller Page, navigate to the Programming section.
• Click on the Seasonal Adjust button.

Step 3: Adjust Seasonal Percentages

• View the seasonal adjust settings for your selected program. The default is set at 100%.

  For example for a 10-minute zone:

  • 100% will run a 10-minute zone for 10 minutes.
  • 50% will run it 5 minutes.
  • 120% will run it for 12 minutes.
  • 5% will run it for 30 seconds.
• Click Edit Seasonal Adjustment to make changes.
• When the pencil icon appears, click the drop-down menu.
• Select a percentage from 0% to 300% to adjust your runtime.

Step 4: Copy Seasonal Adjust Settings (Optional)

• If you'd like to apply the settings from Program A to Program B, click the Copy Program A to B button.
• This will automatically save and apply the same settings to Program B.

Step 5: Save and Send Changes

• After making adjustments, click Stop Editing to save your changes.
• At the top of the page, click the Send button to apply the changes to your controller.
• The communication process may take a few minutes.
• A green Successfully Sent banner will appear once the update is complete.
