How to Adjust Master Valve (MV) to Zone Delay in SmartLink

Learn how to Adjust the Master Valve (MV) to Zone Delay in SmartLink Network by following the instructions below

Step 1: Log In and Select Your Controller

1. Go to smartlinknetwork.com and enter your login credentials to access your account.
2. On the Site Page, find the search bar and type in and select your Site Name from the search results.
3. Then click on the Controller name
   -OR-
4. Locate the Controller List at the top, then find and click the Controller name.

Step 2: Access the Advanced Menu

1. Navigate to the Advanced Programming / Menu tab on the Controller Page.

Step 3: Adjust the Master Valve to Zone Delay

1. Find the Master Valve to Zone Delay setting.
2. Understand that this setting allows the master valve to open before the zone valves to pressurize the main line while keeping all inactive zone valves closed.
3. Adjust the delay time to your preference or set it to 0 seconds for the master valve and zone valve to open at the same time.
4. We recommend keeping the factory default setting of 2 seconds.

Step 4: Save and Send Changes

1. After making your adjustments, click Save Advanced Settings.
2. Click Send to apply the changes to your controller.
3. Confirm that your updates were sent successfully by checking for a green Successfully Sent banner.
