How to Use Pick Columns to Review Controller Details in SmartLink

Updated

Learn how to use Pick Columns to Review Controller Details in SmartLink Network by following the instructions below





Step 1: Log in and Access the Controllers Tab

  1. Open your web browser and go to smartlinknetwork.com.
  2. Enter your SmartLink credentials and click Log In.
  3. Once logged in, locate and click on the Controllers tab in the top navigation bar.
  4. The Controllers page will display a table of all your controllers across all sites.



Step 2: Access the Pick Columns Feature

  1. In the Controllers table view, look to the top right corner of the table.
  2. Click on the Pick Columns button to open the column selection panel.
  3. A menu will appear listing all available data fields that can be shown or hidden in the table.



Step 3: Select Controller Data Fields

  1. Review the list of available columns in the Pick Columns menu.
  2. Check the boxes next to the data fields you want to display.
    Recommended columns include:
    • Controller Name
    • Run Status – Indicates if the controller is running or off
    • Watering Mode – Shows Smart or Basic mode
    • Rain/Freeze Sensor – Displays sensor activity status
    • Faults – Highlights any current alerts
  3. Uncheck any columns that are not relevant to your workflow.
  4. When finished selecting, proceed to apply your changes.



Step 4: Apply Changes

  1. After making your column selections, click the Update Table button at the bottom of the Pick Columns panel.
  2. The controller table will immediately refresh and display only the selected data fields.
  3. Review the updated table to ensure your desired information is now visible.



Step 5: Sort and Analyze

  1. Click on any column header (e.g., Run Status or Faults) to sort the data by that column.
  2. Use this sorting feature to quickly identify controllers that may require attention (e.g., showing faults or inactive sensors).
  3. Repeat for different columns to view your data from multiple perspectives.



Step 6: Export for Sharing

  1. To create a report or share your customized view, locate the Export button (usually near the top or bottom of the controller table).
  2. Click Export to download the current table view as a CSV file.
  3. Open the CSV file using Excel or another spreadsheet tool to format, analyze, or distribute the report as needed.



Step 7: Adjust Anytime

  1. If your needs change, you can return to the Pick Columns menu at any time.
  2. Repeat the selection and update steps to modify which data fields are shown.
  3. This flexibility allows you to adapt your dashboard for different tasks, seasons, or team preferences.



Still Need Help?

If you have any questions, please email us at support@weathermatic.com or call us at 888-484-3776.

Thank you!
