How to Send Quick Commands through Global Commands

Learn how to send Quick Commands to your controllers through the Global Command menu in SmartLink by following the instructions below

Step 1: Log into SmartLink and Navigate to the Controllers Page

1. Navigate to smartlinknetwork.com and sign in.
2. From the top menu, click on Controllers (next to Site and Inspection).
   • This page will show all controllers associated with your profile.
3. Use the search bar to filter controllers by site name or specific keywords if needed.

Step 2: Select Controllers to Send Commands

1. Check the box next to each individual controller you want to select.
2. To select all controllers, check the box next to Site at the top left.

Step 3: Open the Global Command Menu

1. Click Global Command in the top right
2. Select Send Quick Command from the menu.

Step 4: Choose a Quick Command

The Quick Command window will appear with several options:

1. Remote On – Remotely turn controllers on.
2. Remote Off – Remotely turn controllers off.
3. Rain Delay – Set a rain delay for a specified number of hours or days.
4. Clear All Faults – Clear any existing controller faults.
5. Standard Receive – Update controller status, weather, and programming changes.
6. Take Snapshot – Save a snapshot of the controller’s programming settings.
7. Stop All – Stop all operating programs or zones until the next command.

Step 5: Execute the Quick Command

After selecting your desired command:

1. Click Execute Command at the bottom left.
2. View the command status and history as it processes.

Step 6: Review Command Status

1. Green bubbles indicate commands that were sent successfully.
2. Red bubbles indicate failed commands.
   • Click Retry next to a failed command to attempt to send it again.
3. Click on any command bubble to view more details on the Controller Summary page.
