How to Configure the Flow Sensor in SmartLink Network

Updated

Learn how to configure your flow sensor using SmartLink Network by following the instructions below





Step 1: Log In and Select Your Controller

  1. Go to smartlinknetwork.com and enter your login credentials to access your account.
  2. On the Site Page, find the search bar and type in and select your Site Name from the search results.
  3. Then click on the Controller name
    -OR-
  4. Locate the Controller List at the top, then find and click the Controller name.



Step 2: Access the Flow Settings Page

  1. Confirm that your Flow subscription is active. If not, go to the subscriptions section to add it.
  2. Navigate to the Flow page.
  3. Click on Edit Flow Settings to begin configuration.



Step 3: Select Your Flow Sensor Model

  1. If you are using a non-Weathermatic sensor, select Custom.
  2. For Weathermatic sensors, choose from the following options:
    • T10 for 1 inch plastic tee.
    • B15 for 1.5 inch brass tee.
    • S30 for 3 inch saddle.
  3. Select the appropriate sensor model for your system.



Step 4: Set the Line Fill Time

  1. Determine how long it takes to purge air from the furthest zone on your system.
  2. Enter this time in seconds under Line Fill Time. For example, if it takes 2 minutes, enter 120 seconds.



Step 5: Adjust Sample Time

  1. By default, the sample time is set to 60 seconds.
  2. You can adjust this time if needed for a higher resolution of flow data.



Step 6: Choose a Flow Shutdown Mode

  1. Select between the two shutdown modes:
    • System: The program will shut down the master valve after two consecutive flow errors.
    • Per Zone: The system will attempt to run all zones, flagging any zones with flow issues.
  2. Choose the mode that best fits your needs.



Step 7: Configure Leak Detection

  1. For Normally Open Master Valves, set an acceptable water usage level.
  2. For Normally Closed Master Valves, enter a small positive value like 3 gallons per minute to avoid false alarms.



Step 8: Save, Send, and Verify Changes

  1. Click Save at the bottom of the page to apply your settings.
  2. Click the red Send button to send the settings to your controller.
  3. Wait for the green confirmation banner that says Instruction Completed.
  • (Optional) Navigate to the Recent Events section and Confirm the changes were applied successfully.
