How to Set the Slope in SmartLink Network

Updated

Learn how to set the slope for your zones in Smart Mode using SmartLink Network by following the instructions below





Step 1: Log In and Select Your Controller

  1. Go to smartlinknetwork.com and enter your login credentials to access your account.
  2. On the Site Page, find the search bar and type in and select your Site Name from the search results.
  3. Then click on the Controller name
    -OR-
  4. Locate the Controller List at the top, then find and click the Controller name.



Step 2: Access Smart Mode Settings

  1. On the Controller Page, scroll down to the Programming section.
  2. Click the Smart Mode Auto Adjust button.



Step 3: Edit Slope Settings

  1. Under the Slope column, you will see the current slope values for each zone. By default, these may be set to 0.
  2. Hover over the Slope label to view additional information on how slope adjustments impact your irrigation system.
  3. Click Edit Smart Settings to enter edit mode.
  4. Select the Pencil Icon next to the slope value you want to modify.
  5. Select the desired slope value in the drop down box. Higher slope values increase the run/soak cycle to prevent water runoff, depending on the Soil Type.

See the attached Run Soak table for a breakdown of each soil and slope value combination



Step 4: Save and Send Changes

  1. After making your adjustments, click Stop Editing to save your selections.
  2. Click the red Send button at the top right corner to apply your changes to the controller.
  3. The system will show a Successfully Sent banner once the communication is complete.
