How to Set Soil Type in SmartLink Network

Learn how to set your soil type for Smart Mode settings in SmartLink Network by following the instructions below

Step 1: Log In and Select Your Controller

1. Go to smartlinknetwork.com and enter your login credentials to access your account.
2. On the Site Page, find the search bar and type in and select your Site Name from the search results.
3. Then click on the Controller name
   -OR-
4. Locate the Controller List at the top, then find and click the Controller name.

Step 2: Access Smart Mode Settings

1. On the Controller Page, scroll down to the Programming section.
2. Click the Smart Mode Auto Adjust button.

Step 3: Edit Soil Type

1. Under the Soil Type column, you will see the current soil types for each zone. By default, these may be set to Clay.
2. Hover over the Soil Type menu to view additional information on each soil type.
3. Click Edit Smart Settings to enter edit mode.
4. Select the Pencil Icon next to the soil type you want to modify, or click anywhere in the box.
5. Choose from the following options in the drop down menu:
   • Sand: Allows for minimal run/soak time as water percolates quickly.
   • Loam: Offers moderate run/soak cycles.
   • Clay: Provides the most run/soak time to minimize runoff.

For further details, refer to Section 4.2.3 of the attached SmartLine Owner’s Manual.

Step 4: Save and Send Changes

1. After making your adjustments, click Stop Editing to save your selections.
2. Click the red Send button at the top right corner to apply your changes to the controller.
3. The system will show a Successfully Sent banner once the communication is complete.
