How to Manually Run a Zone from SmartLink

Learn how to manually run a zone from SmartLink Network by following the instructions below

Step 1: Log In and Select Your Controller

1. Go to smartlinknetwork.com and enter your login credentials to access your account.
2. On the Site Page, find the search bar and type in and select your Site Name from the search results.
3. Then click on the Controller name
   -OR-
4. Locate the Controller List at the top, then find and click the Controller name.

Step 2: Access the Manual Run Section

1. On the Controller Page, locate the Manual Run section in the middle of the page.
2. Click on the Run Zone option.

Step 3: Choose a Zone and Duration

1. Use the Select a Zone drop down to choose the desired zone (e.g., Zone 1).

• By default, the run time will be set to 1 minute, but you can adjust it up to 9 hours and 55 minutes.
• Note: Selecting a zone will disable the Valve Locator and Run Program options.

Step 4: Start the Zone

1. Click Start when ready.
2. SmartLink will communicate with your controller and confirm the command.
3. A Send Completed Successfully message will appear within a few seconds.

Step 5: Manage the Zone

• Once the zone completes its run time, the controller will resume its previous activity (e.g., running a program or another zone).
• You can also:
  • Click Stop All to stop the current zone.
  • Select another Zone or Program to run.
  • Starting a new zone or program will stop any active operations.
