How to Build a Flow Report

Learn how to build a Flow Report using the data your flow sensor sends to your Flow Air Card by following the instructions below

Step 1: Navigate to the Reports Section

1. Log in to your SmartLink account at smartlinknetwork.com
2. Navigate to the controller's Site Page.
3. Click the Report button at the top of the page.

Step 2: Clear Existing Data (Optional)

1. By default, you will see the high and low temperatures from your weather sensor (if available) and the run times for the past 7 days.
2. If you prefer a clean graph, click the X buttons to remove any unwanted data.

Step 3: Select Your Reporting Items

1. Under Reporting Items, ensure the correct Site is selected.
2. If you have multiple controllers, change the selection from All Controllers to a specific controller.

Step 4: View All Zones Grouped

1. Select All Zones Grouped as your view option.
2. Under the SmartLink Controller section, change the data from Run Times to Gallons.
3. Click Add to generate the report.

Step 5: Adjust the Time frame

1. If there isn’t much data from the past 7 days, adjust the timeline using the pre-selected options.
2. Choose from options like Past 30 Days or Past 3 Months.
3. For example, on December 8, 2024, all zones combined may show a total of 10,082 gallons used.
4. You can switch to a Daily View to see detailed data, such as 3,386 gallons used on that specific day.

Step 6: View Zones Individually

1. To see data for each zone separately, clear the current data using the X buttons.
2. Change the selection from All Zones Grouped to Individually.
3. Click Add to view zone-specific data.
4. Adjust the timeline to Past 30 Days or another desired period to get detailed insights.

Step 7: Save Your Report

1. If you want to save the report for future use, click the Save As button.
2. Enter a name for the report, such as Daily Gallons.
3. Click OK to confirm.
4. If the timeline reverts, simply adjust it back to your preferred view.

Step 8: Download or Delete Your Report

1. To keep a copy of your report, you can:
   • Download it as a CSV file.
   • Export it to an Excel file.
2. If you no longer need the report:
   • Click Delete Report.
   • Confirm by clicking OK.
